Phohom's metal clad plates, dissimilar metal joints are reliable to be used for making industrial equipments such as pressure vessels, heat exchangers, ships, etc. As China's leading manufacturer of clad plates, we can achieve more than 300 dissimilar metal combinations by our explosive welding process. In dissimilar metal welding, steel is the most common base material. According to purpose of use, stainless steel, aluminum, copper and titanium can be used as cladding metal and base metal steel to achieve metallurgical bonding.
The thickness and production standards of Phohom's clad plates can be customized to meet demanding material design from different application scenarios, especially in industries of petrochemicals, natural gas and metallurgical smelting industry, which can't be solved by roll bond and weld overlay solutions.
Metal Smelting I Petrochemical | Heat Exchange Equipment | Shipbuilding
- Clad Plates
- For clad plate and clad tube sheet, they can be used in the construction of pressure vessels and chemical equipment, where they provide excellent corrosion resistance and mechanical strength to ensure the long-term stable operation of these facilities.
| Base Metal | Grades | Clad Steel | Grades |
|---|---|---|---|
| ASME SA516 | Gr.60, 65, 70 | Stainless Steel | 410S,405,304,304L,321 |
| ASME SA105 | 316L,316Ti, 317L, 347H | ||
| ASME SA350 | LF1, LF2, LF3 | S31803(2205),N08904(904L) | |
| ASME SA387 | Gr.11,12,21,22 | Nickel Alloy | N02200(200), N02201(201), N04400(400) |
| ASME SA182 | F1, 11, 12, 21, 22 | N06600(600)/6625 | |
| ASME SA336 | F21Gr.1-3,F12,F11,Gr.1 | N08800(800)/8825, N08028(Alloy28) | |
| ASME SA240 | TP304L | N10276(C-276), N06022(C-22) | |
| ASME SA182 | F304L | N106455(C-4),N06059(59#) | |
| ASME SA266 | all Classes | Titanium Alloy | Gr.1,Gr.11, Gr17 |
| ASME SA765 | CL2 | Copper Nickel | C70600, C71500 |
| ASME SA204 | Copper | C10200,C10400,C10500,C1100 | |
| ASME SA302 | Aluminum | C6300, C61400 |
Capacity
| Maximum width | 4200 mm |
| Maximum length | 13000 mm |
| maximum total area | 50 ㎡ |
| maximum number of layers | 11 |
| Base metal thickness | 0.2-500 mm |
| Clad metal thickness | 0.1-100 mm |
N04400(400) + ASME SA516 Gr.60
B265 Gr.2 + ASME SA516 Gr.70
1070 + Q235B
3003 + TA1 + 316L
